Full scale replica of Boeing 737 MODE CONTROL PANEL
14 custom made switches with dual color legends: white backlighted text and neutral indicator with green light status. This, like in the real aircraft, allows high visibility only when in active status.
3 round pushbuttons to select CO, ALT INT and SPEED INT functions.
Electromagnetic Auto Throttle ARM switch with green led indicator.
Custom high resolution warm white backlighting frontplate.
White color LED 7 segment Displays for Altitude, VS, Heading, IAS, Left and Right Course.
New Grayhill® High torque Optical encoders
Aluminium dust-coated knobs (with symbols on course knobs).
Bank angle selector with high reliability swiss made dual concentric HDG-SEL knobs (10°, 15°, 20°, 25°, 30°).
Ambient light sensor for display brightness regulation.
External or internal backlight brightness regulation.
External AT disengage.
16 bit flash memory technology to upgrade the built-in operating program (for eventual future improvements and expansions).
Central unit for daisy-chained connection of Efis selector (Captain and F/O), Mip and radios.
Ethernet Interface (Ethernet cable provided), 6Vdc 1A power supply (provided).
Compatible with Flight Simulator X, Flight Simulator Steam Edition, Prepar 3D ( V1, V2, V3, V4 and V5), Project Magenta, PROSIM737, PMDG737NGX(NGXu), iFly737.
Internal ethernet bootloader for easy upgrade.
Full scale replica of Boeing EFI737 selector.
Custom high resolution backlighting frontplate.
Triple concentric devices for MINS and BARO regulation.
RADIO/BARO and IN/HPA are two positions 60° index rotary switches.
MINS and BARO regulation (middle knobs) are real as in the aircraft.
RST and STD pushbuttons (inner buttons) have a separate shaft to guarantee a correct label orientation.
Double concentric devices for the MODE and RANGE commutators.
MODE and RANGE commutators (outer knobs) are respectively 4 and 8 positions 30°index.
TFC and CTR pushbuttons (inner buttons) have a separate shaft to guarantee a correct label orientation.
Compatible with Flight Simulator X, Flight Simulator Steam Edition, Prepar 3D ( V1, V2, V3, V4 and V5), Project Magenta, PROSIM737, SimAvionics, PMDG737NGX(NGXu), iFly737, LVLD767, XP11 (Zibo737).
Fixing clamp and 5 pole connection cable lenght ( 70 cm - provided).
Full scale replica of Boeing 737 MODE CONTROL PANEL
Electromagnetic disengage Auto Throttle ARM switch.
Custom high resolution Warm white backlighted frontplate.
White color LED 7 segment Displays for Altitude, VS, Heading, IAS, Left and Right Course.
Aluminium powder-coated knobs (with symbols on course knobs).
Dual concentric HDG-SEL knobs with 5 positions BANK ANGLE limit selector (10°, 15°, 20°, 25°, 30°).
External or internal display and backlight brightness regulation.
External AT disengage.
Central unit for daisy-chain connection of Efis selector (Captain and F/O), Mip and radios
USB Interface (USB cable provided), 6Vdc 1A power supply (provided)
Compatible with Flight Simulator X, Flight Simulator Steam Edition, Prepar 3D ( V1, V2, V3, V4 and V5), Project Magenta, PROSIM737, SimAvionics, PMDG737NGX(NGXu), iFly737, LVLD767, xPlane.
Full scale replica of Boeing EFI737MAX selector.
Custom high resolution backlighting frontplate.
Triple concentric devices for MINS and BARO regulation.
RADIO/BARO and IN/HPA are two positions 60° index rotary switches.
MINS and BARO regulation (middle knobs) are real as in the aircraft.
RST and STD pushbuttons (inner buttons) have a separate shaft to guarantee a correct label orientation.
Double concentric devices for the MODE and RANGE commutators.
4 position MODE rotary selector (30°)
RANGE commutators (30°) to increase or decrease the range scale.
TFC and CTR pushbuttons (inner buttons) have a separate shaft to guarantee a correct label orientation.
Compatible with Flight Simulator X, Flight Simulator Steam Edition, Prepar 3D (V1, V2, V3, V4 and V5), Project Magenta, PROSIM737 MAX version.
Fixing clamp and 5 pole connection cable lenght ( 70 cm - provided).
Display resolution 1200x1200
Ethernet connection
High intensity LED Backlight
RST pushbutton
APP pushbutton
HP/IN pushbutton
+ and -pushbutton to regulate the display brightness
Encoder for altimeter setting
Encoder pushbutton for STD setting
Compatible with Project Magenta and Prosim737
Configuration menù for automatic firmware upgrade, change ip, DHCP or static ip
No need video output from the PC
Power supply and Ethernet cable provided
Full scale replica of Boeing 737 MODE CONTROL PANEL.
Custom Warm white backlighted frontplate.
Yellow digit to displays Altitude, VS, Heading, IAS , Left and Right Course.
Knobs with symbols on course (both), heading and altitude.
C/O, Speed and Alt Intervention round buttons.
External or internal display and backlight brightness regulation.
Central unit for daisy-chained connection of Efis selector (Captain and F/O), Mip and radios
DIN 5 pole socket for plug&play CPflight modules interface.
USB Interface (USB cable provided).
Compatible with Flight Simulator X, Flight Simulator Steam Edition, Prepar 3D ( V1, V2, V3, V4 and V5), Project Magenta, PROSIM737, SimAvionics, PMDG737NGX(NGXu), iFly737, LVLD767, XP11 (Zibo737).
Full scale replica of Boeing EFI737 selector.
Custom warm white backlighted frontplate.
Custom MAP buttons with backlighted text.
2 rotary encoders with push in switch for MINS and BARO adjustment.
Knobs with printed symbols.
Fixing clamp and 5 pole connection cable ( 70 cm provided ).
RADIO/BARO and IN/HPA selection ( push and rotate simultaneously).
Full scale replica of Boeing 737 Central Unit Display, look and functionality are reproduced with high details. CDU737PRO is an ethernet connection hardware and use TCPIP protocol to interface with the used addon.
CDU737PRO is equipped with:
- Backlighted custom made keyboard
- Own 640x480 color display (No need to connect to any video output of your PC)
- Ethernet cable to allow you to connect the CDU737PRO to your LAN
- 12 Vdc 2 A Power supply
- Fastners and dzus to fix to your structure
- Compatible with Prosim737, Project Magenta, PMDG737ngx, PMDG737ngxu and iFly737.
To know more about the CDU compatibility with a specific add-on aircraft please refer to the technical and documents section
Full scale replica of Boeing 737 Central Unit Display, look and functionality are reproduced with high details.
CDU737 is equipped with:
- custom made keyboard
- HDMI 640x480 color display with HDMI port to connect to the PC
- 5 pole daisy chain connection
-compatible with Project Magenta, Prosim737, PMDG737 and further developments.
The package includes also 12V 2A power supply adapter, 3 mt. long HDMI cable, fixing fastners kit and 1 mt 5 pole cable.
This module allows the connection in daisy chain with all the other CPflight modules. It needs only MCP737EL/PRO/PRO2 to function.
To know more about the CDU compatibility with a specific add-on aircraft please refer to the “technical and documents†section. Logics, operating modes and aircraft way of behaving are managed by the software.
The module is complete and ready to use and does not require additional cards or software programming.
No need for PC software programs to configure CDU737 hardware.
Full scale replica of Boeing 737 OVERHEADNG FWD panel.
Frontplate with warm white backlight.
Electromagnetic START SWITCHES
Electromagnetic YAW-DAMPER, WING ANTI-ICE and VOICE RECORDERswitches
Pushbutton for annunciator test.
OVH737NG_FWD is supplied with all the gauges.
DVM display with green digit.
Display characteristics: LED 7 segment. Digit height: 0,3" (7,6 mm).
Displays: FLT ALT and LAND ALT yellow digit.
2 encoders to set FLT ALT and LAND ALT.
Encoders characteristics: Half million cycle rated, 32 increment for rotation (with detent).
High reliability switches with locking lever (where required).
12Vdc 5A power supply adapter (provided)
Ethernet Interface (Ethernet cable provided).
Compatible with Flight Simulator X, Flight Simulator Steam Edition, Prepar 3D ( V3, V4 and V5), Project Magenta, PROSIM737, PMDG737NGX, iFly737.
Please note that the delivery time of this product could change, normally is between 1 and 3 weeks.
Full scale replica of Boeing737NG OVERHEAD AFT PANEL.
Frontplate with warm white backlight.
Pushbuttons with annunciator test function.
ACP with volume regulation active on all channels
OXI gauge.
IRS graphic display with brightness regulation.
Guarded EEC pushbutton
PULL & Rotate functionality to set OFF position on IRS selectors
Bipolar DOME WHITE switch to separately drive one other device ( LAMP ecc.... )
Compatible with Flight Simulator X, Flight Simulator Steam Edition, Prepar 3D ( V3, V4 and V5), Project Magenta, PROSIM737 V3, PMDG737NGX, iFly737.
OVH737NG_AFT is intended for CPflight daisy chain connection. Does not require further driver installations, software configurations or any additional power supply.
OVH737NG_AFT PANEL is an expansion module and require B737 ELECTRICAL PANEL ( see FWD overhead ) to operate so don't use other computer's input. The ELECTRICAL PANEL performs the function of “central unit” for all the other modules that make the overhead
OVH737NG_AFT PANEL is exclusively compatible with the OVH737NG_FWD PANEL ( Ethernet version )
Full scale replica of Boeing 737 OVERHEADMAX FWD panel.
Frontplate with warm white backlight.
Electromagnetic START SWITCHES
Electromagnetic YAW-DAMPER, WING ANTI-ICE and VOICE RECORDERswitches
Pushbutton for annunciator test.
OVH737MAX_FWD is supplied with all the gauges.
DVM display with green digit.
Display characteristics: LED 7 segment. Digit height: 0,3" (7,6 mm).
Displays: FLT ALT and LAND ALT white digit.
2 encoders to set FLT ALT and LAND ALT.
Encoders characteristics: Half million cycle rated, 32 increment for rotation (with detent).
High reliability switches with locking lever (where required).
12Vdc 5A power supply adapter (provided)
Ethernet Interface (Ethernet cable provided).
Compatible with Flight Simulator X, Flight Simulator Steam Edition, Prepar 3D ( V3, V4 and V5), Project Magenta, PROSIM737, PMDG737NGX, iFly737.
Please note that the delivery time of this product could change, normally is between 1 and 3 weeks.
Full scale replica of Boeing 737 OVERHEAD FWD PANEL.
ELECTRICAL panel is the main module. Is the central unit of the Overhead737 system, the other modules like OVH737 BRIGHT panel and OVH737 LIGHT are connected directly in daisy chain to the main module.
Is provided pre-assembled with all you need to finish to assembly and to connect to the simulator
Other modules can be add time by time
In the technical and Manual section you can find the assembly manual, helpful to fix the modules to the frame
Frontplate with warm white backlight.
Electromagnetic START SWITCHES
Pushbutton for annunciator test.
DVM display with green digit.
Display characteristics: LED 7 segment. Digit height: 0,3" (7,6 mm).
High reliability switches with locking lever (where required).
12Vdc 5A power supply adapter (provided)
Ethernet Interface (Ethernet cable provided).
Compatible with Flight Simulator X, Flight Simulator Steam Edition, Prepar 3D ( V1, V2 and V3), Project Magenta, PROSIM737, PMDG737NGX, iFly737.
Please note that the delivery time of this product could change, normally is between 1 and 3 weeks.
Full Scale replica of the Boeing737 Flight Control Panel and Navigation Panel
Custom high resolution warm white backlighting frontplate.
Annunciators pushbutton test functionality
Original APEM LOCK-LOCK-LOCK switch with white CAP, customized directly by APEM only for CPflight
Yaw damper switch with electromagnetic disengage
Painted 1/4 Turn Original Fastners ( 10 pieces provided )
Provided with a 4 pole cable for daisy chain interface with the main module ( B737 ELECTRICAL PANEL )
Compatible with Prosim737 V3, Project Magenta, PMDG737NGX, PMDG737NGX series and iFly737
B737 FLIGHT CONTROL PANEL is intended for CPflight daisy chain connection. Does not require further driver installations, software configurations or any additional power supply.
B737 FLIGHT CONTROL PANEL is an expansion module and require B737 ELECTRICAL PANEL to operate so don't use other computer's input like usb port. The ELECTRICAL PANEL performs the function of “central unit” for all the other modules that make the overhead
Full Scale replica of the Boeing737 FUEL TEMP Panel
Custom high resolution warm white backlighting frontplate.
Annunciators pushbutton test functionality
Original APEM LOCK-LOCK switch with white CAP, customized directly by APEM only for CPflight
FUEL TEMP Backlighted Gauge
Painted 1/4 Turn Original Fastners ( 6 pieces provided )
Provided with a 4 pole cable for daisy chain interface with the main module ( B737 ELECTRICAL PANEL )
Compatible with Prosim737 V3, Project Magenta, PMDG737NGX, PMDG737NGX series and iFly737
B737 FUEL TEMP PANEL is intended for CPflight daisy chain connection. Does not require further driver installations, software configurations or any additional power supply.
B737 FUEL TEMP PANEL is an expansion module and require B737 ELECTRICAL PANEL to operate so don't use other computer's input like usb port. The ELECTRICAL PANEL performs the function of “central unit” for all the other modules that make the overhead
Full Scale replica of the Boeing737 APU EGT Panel
Custom high resolution warm white backlighting frontplate.
Annunciators pushbutton test functionality
Original APEM MOM-LOCK-MOM switch with white CAP, customized directly by APEM only for CPflight
APU EGT Backlighted Gauge
Boeing Style backlighted knob for L Viper function
Painted 1/4 Turn Original Fastners ( 6 pieces provided )
Provided with a 4 pole cable for daisy chain interface with the main module ( B737 ELECTRICAL PANEL )
Compatible with Prosim737 V3, Project Magenta, PMDG737NGX, PMDG737NGX series and iFly737
B737 APU EGT PANEL is intended for CPflight daisy chain connection. Does not require further driver installations, software configurations or any additional power supply.
B737 APU EGT PANEL is an expansion module and require B737 ELECTRICAL PANEL to operate so don't use other computer's input like usb port. The ELECTRICAL PANEL performs the function of “central unit” for all the other modules that make the overhead
Full Scale replica of the Boeing737 PANEL BRIGHT
Custom high resolution warm white backlighting frontplate.
Annunciators pushbutton test functionality
Boeing Style backlighted knob for R Viper function
3 position EMER EXT LIGHT switch with costumized black guard that when closed leave the switch in ARMED position
2 boeing style backlighted knobs for bright regulation of BRIGHT PANEL e CIRCUIT BREAKER
Provided with a 4 pole cable for daisy chain interface with the main module ( B737 ELECTRICAL PANEL )
Compatible with Prosim737 V3, Project Magenta, PMDG737NGX, PMDG737NGX series and iFly737
B737 BRIGHT PANEL is intended for CPflight daisy chain connection. Does not require further driver installations, software configurations or any additional power supply.
B737 BRIGHT PANEL is an expansion module and require B737 ELECTRICAL PANEL to operate so don't use other computer's input like usb port. The ELECTRICAL PANEL performs the function of “central unit” for all the other modules that make the overhead
Full Scale replica of the Boeing737 Wing Anti Ice Panel
Custom high resolution warm white backlighting frontplate.
Annunciators pushbutton test functionality
Original APEM LOCK-LOCK switch with white CAP, customized directly by APEM only for CPflight
Wing Anti Ice switch with electromagnetic disengage
Painted 1/4 Turn Original Fastners ( 8 pieces provided )
Provided with a 4 pole cable for daisy chain interface with the main module ( B737 ELECTRICAL PANEL )
Compatible with Prosim737 V3, Project Magenta, PMDG737NGX, PMDG737NGX series and iFly737
B737 WING ANTI ICE panel is intended for CPflight daisy chain connection. Does not require further driver installations, software configurations or any additional power supply.
B737 WING ANTI ICE panel is an expansion module and require B737 ELECTRICAL PANEL to operate so don't use other computer's input like usb port. The ELECTRICAL PANEL performs the function of “central unit” for all the other modules that make the overhead
Full Scale replica of the Boeing737 HYD PUMPS Panel
Custom high resolution warm white backlighting frontplate.
Annunciators pushbutton test functionality
Original APEM LOCK-LOCK switch with white CAP, customized directly by APEM only for CPflight
CABIN CLIMB Backlighted Gauge
DIFF PRESS & CABIN ALT Backlighted Gauge
Painted 1/4 Turn Original Fastners ( 16 pieces provided )
Provided with a 4 pole cable for daisy chain interface with the main module ( B737 ELECTRICAL PANEL )
Compatible with Prosim737 V3, Project Magenta, PMDG737NGX, PMDG737NGX series and iFly737
B737 HYD PUMPS PANEL is intended for CPflight daisy chain connection. Does not require further driver installations, software configurations or any additional power supply.
B737 HYD PUMPS PANEL is an expansion module and require B737 ELECTRICAL PANEL to operate so don't use other computer's input like usb port. The ELECTRICAL PANEL performs the function of “central unit” for all the other modules that make the overhead
Full Scale replica of the Boeing737 AIR TEMP & VOICE RECORDER Panel
Custom high resolution warm white backlighting frontplate.
Annunciators pushbutton test functionality
Original APEM LOCK-LOCK switch with white CAP, customized directly by APEM only for CPflight
Voice Recorde switch with electromagnetic disengage
Original APEM LOCK-LOCK-LOCK switch with white CAP, customized directly by APEM only for CPflight
AIR TEMP Backlighted Gauge
DUCT PRESS L & R Backlighted Gauge
Painted 1/4 Turn Original Fastners ( 12 pieces provided )
Provided with a 4 pole cable for daisy chain interface with the main module ( B737 ELECTRICAL PANEL )
Compatible with Prosim737 V3, Project Magenta, PMDG737NGX, PMDG737NGX series and iFly737
B737 AIR TEMP & VOICE RECORDER PANEL is intended for CPflight daisy chain connection. Does not require further driver installations, software configurations or any additional power supply.
B737 AIR TEMP & VOICE RECORDER PANEL is an expansion module and require B737 ELECTRICAL PANEL to operate so don't use other computer's input like usb port. The ELECTRICAL PANEL performs the function of “central unit” for all the other modules that make the overhead
Full Scale replica of the Boeing737NG DIGITAL PRESS CONTROLLER Panel
Custom high resolution warm white backlighting frontplate.
3 Position switch
Boeing style backlighted knob
OUTFLOW VALVE Backlighted Gauge
Painted 1/4 Turn Original Fastners ( 6 pieces provided )
Provided with a 4 pole cable for daisy chain interface with the main module ( B737 ELECTRICAL PANEL )
Compatible with Prosim737 V3, Project Magenta, PMDG737NGX, PMDG737NGX series and iFly737
B737NG DIGITAL PRESS CONTROLLER PANEL is intended for CPflight daisy chain connection. Does not require further driver installations, software configurations or any additional power supply.
B737NG DIGITAL PRESS CONTROLLER PANEL is an expansion module and require B737 ELECTRICAL PANEL to operate so don't use other computer's input like usb port. The ELECTRICAL PANEL performs the function of “central unit” for all the other modules that make the overhead
Full Scale replica of the Boeing737NG LIGHT panel
Custom high resolution warm white backlighting frontplate.
3 position switch with customized cap for RETRACTABLE landing light
2 position switch with customized cap for FIXED landing light
Original APEM MOM-LOCK-LOCK switch with white CAP for APU ON/OFF and START function
2 Boeing style BACKLIGHTED knob on the start switches
2 start switches with electromagnetic disengage to switch between GRD to OFF position
Provided with a 4 pole cable for daisy chain interface with the main module ( B737 ELECTRICAL PANEL )
Compatible with Prosim737 V3, Project Magenta, PMDG737NGX, PMDG737NGX series and iFly737
B737NG LIGHT PANEL is intended for CPflight daisy chain connection. Does not require further driver installations, software configurations or any additional power supply.
B737NG LIGHT PANEL is an expansion module and require B737 ELECTRICAL PANEL to operate so don't use other computer's input like usb port. The ELECTRICAL PANEL performs the function of “central unit” for all the other modules that make the overhead
Full Scale replica of the Boeing737 ELECTRICAL Panel
Custom high resolution warm white backlighting frontplate.
Annunciators pushbutton test functionality
2 and 3 position switches with guard
Boeing style BACKLIGHTED knobs for DC and AC METER SELECTOR rotary switches
Ethernet cable ( provided )
Painted 1/4 Turn Original Fastners ( 14 pieces provided )
Provided with power supply 12Vdc 5A
Compatible with Prosim737 V3, Project Magenta, PMDG737NGX, PMDG737NGX series and iFly737
The ELECTRICAL PANEL performs the function of “central unit” of the daisy chain bus for all the other modules that make the overhead
ELECTRICAL PANEL is connected through a TCPIP protocol to the LAN.
Full scale replica of Boeing 737 OVERHEAD AFT PANEL.
Frontplate with warm white backlight.
Only for OVH737FWD usb version.
Pushbuttons with annunciator test function.
OVH737FWD comes provided with OXI gauge.
IRS graphic display.
The OVH737AFT is an extension of OVH737FWD panel and requires OVH737FWD usb version only to work.
Compatible with Flight Simulator X, Flight Simulator Steam Edition, Prepar 3D ( V1, V2 and V3), Project Magenta, PROSIM737, PMDG737NGX, iFly737.
Please note that the delivery time of this product could change, normally is between 1 and 3 weeks.
Full Scale MIP Structure
RAL 7011 metal structure and casings
Black Glareshield
MCP and EFIS bracket included
Display Bezels Included
Easy assembly
Ready to install with all CPflight modules (MCP737, EFIS,MIP737ICS, SIDE737)
Compatible with FSC B737NG PRO rudder pedals upfloor - CPT and FO side
Plug & play system to connect directly to the MIP structure.
No need of any configuration file or script
Frontplate with warm white backlight.
Switches, rotary, annunciators, LED's and knobs are already installed and working.
Working Yaw Damper indicator.
N1 SET and SPEED REF are dual concentric Rotary switches with encoder.
Guarded position ( pull and rotate) to set Autobrake "MAX" position.
Working FLAPS Gauge with 2 indipendent needles to show Left and Right position.
Working Brake Press gauge.
Lower Panel with single and dual concentric potentiometer.
Compatible with Flight Simulator X, Flight Simulator Steam Edition, Prepar 3D ( all versions ), Project Magenta, PROSIM737, PMDG737NGX, iFly737, LVLD767, XP11.
MIP737ICS3_FULL is an expansion module and requires MCP737EL or MCP737PRO/PRO2/PRO3/NG-MAX to operate.
Plug & play system to connect directly to the MIP structure.
No need for any configuration file or script
Frontplate with warm white backlight.
Switches, rotary, annunciators, LED's and knobs are already installed and working.
Working Yaw Damper indicator.
N1 SET and SPEED REF are dual concentric Rotary switches with encoder.
Guarded position ( pull and rotate ) to set Autobrake "MAX" position.
Working FLAPS Gauge with 2 indipendent needles to show Left and Right position.
Compatible with Flight Simulator X, Flight Simulator Steam Edition, Prepar 3D (all versions ), Project Magenta, PROSIM737, PMDG737NGX, iFly737, LVLD767, XP11.
MIP737ICS3_MAIN is an expansion module and requires MCP737EL or MCP737PRO/PRO2/PRO3/NG-MAX to operate.
Plug & play system to connect directly to the MIP structure.
No need of any configuration file or script
Frontplate with warm white backlight.
Switches, rotary, annunciators, LED's and knobs are already installed and working.
Compatible with Flight Simulator X, Flight Simulator Steam Edition, Prepar 3D ( all versions ), Project Magenta, PROSIM737, PMDG737NGX, iFly737, LVLD767, XP11.
MIP737ICS3_CAP is an expansion module and requires MCP737EL or MCP737PRO/PRO2/PRO3/NG-MAX to operate.
Plug & play system to connect directly to the MIP structure.
No need of any configuration file or script
Frontplate with warm white backlight.
Switches, rotary, annunciators, LED's and knobs are already installed and working.
Working Brake Press gauge.
Compatible with Flight Simulator X, Flight Simulator Steam Edition, Prepar 3D ( all versions ), Project Magenta, PROSIM737, PMDG737NGX, iFly737, LVLD767, XP11.
MIP737ICS3_FULL is an expansion module and requires MCP737EL or MCP737PRO/PRO2/PRO3/NG-MAX to operate.
Plug & play system to connect directly to the MIP structure.
No need of any configuration file or script
Frontplate with warm white backlight.
Main Panel backlight regulator
Background and AFDS Flood brightness regulator
Compatible with Flight Simulator X, Flight Simulator Steam Edition, Prepar 3D ( all versions ), Project Magenta, PROSIM737, PMDG737NGX, iFly737, LVLD767, XP11.
MIP737ICS3_CAP is an expansion module and requires MCP737EL or MCP737PRO/PRO2/PRO3/NG-MAX to operate.
MIP737ICS3_FO_LO is an expansion of MIP737ICS3_CP_LO panel
No need of any configuration file or script
Frontplate with warm white backlight.
FO Main Panel backlight regulator
Ground Proximity guarded switches
Sys Test pushbutton and GPWS annunciator
Compatible with Flight Simulator X, Flight Simulator Steam Edition, Prepar 3D ( all versions ), Project Magenta, PROSIM737, PMDG737NGX, iFly737, LVLD767, XP11.
MIP737ICS3_CAP is an expansion module and requires MCP737EL or MCP737PRO/PRO2/PRO3/NG-MAX to operate.
Our MULTI737 disposes of:
• 12 yellow displays 7 segments, to visualize radio frequencies
• 1 encoder for HF sensitivity
• High quality dual concentric encoders with custom made knobs for the frequency selection.
• 5 pole cable, fasteners and screws provided (optional 1/4 turn original fastners)
• Control lights indicating the radio selected and 1 for the Radio Arm
• 9 backlighted pushbuttons with related led indicating which radio has been selected:
• VHF1
• VHF2
• VHF3
• HF1
• HF2
• AM
• TRANSFER
• OFF
• TEST
Full scale replica of Boeing 737 MULTI MODE NAV control panel
Warm white backlight,
LCD display ( 18x64 dot) with yellow digit
Realistic design with real size dimensions
Custom made keyboard
Direct daisy-chain connection to MCP737 through single 5 pole cable (provided)
Compatible with Flight Simulator X and Prepar3D through Project Magenta, PROSIM737 software ( Version V2 and V3 ) and PMDG737ngx & NGXu series.
Easy jumper selection to set MMNAV1 or MMNAV2 functionality
5 pole connection cable ( 70 cm - provided )
The module is provided with aluminium fasteners, screws and nuts (optional 1/4 turn original fastners)
MULTI MODE NAV CONTROL PANEL is an expansion module and requires MCP737EL or MCP737PRO/PRO2/PRO3/NG to operate.
Full scale replica of Boeing 737 navigation radio
Warm white backlight, yellow digit and dual concentric encoder
Realistic design with real size dimensions
Custom made aluminium knobs
Direct daisy-chain connection to MCP737 through single 5 pole cable (provided)
Compatible with Flight Simulator X, Flight Simulator Steam Edition, Prepar 3D ( all releases ), Project Magenta, PROSIM737, SimAvionics, PMDG737NGX, iFly737, LVLD767, xPlane.
Easy jumper selection to set NAV1 or NAV2 functionality
5 pole connection cable ( 70 cm - provided )
The module is supplied with aluminium fasteners, screws and nuts (optional 1/4 turn original fastners)
NAV737 is an expansion module and requires MCP737EL or MCP737PRO/PRO2 to operate.
Full scale replica of Boeing 737 communication radio
Realistic design with real size dimensions
Warm white Backlight, yellow digit and dual concentric encoder
Direct daisy-chain connection to MCP737 through single 5 pole cable (provided)
Easy jumper selection to set COM1 or COM2 functionality
Compatible with Flight Simulator X, Flight Simulator Steam Edition, Prepar 3D ( V1, V2 and V3), Project Magenta, PROSIM737, SimAvionics, PMDG737NGX, iFly737, LVLD767, xPlane.
5 pole connection cable ( 70 cm - provided )
The module is supplied with aluminium fasteners, screws and nuts (optional 1/4 turn original fastners)
VHF737 is an expansion module and requires MCP737EL or MCP737PRO/PRO2 to operate.
Full scale replica of Boeing 737 ADF radio
Warm white backlight, yellow digit and dual concentric encoder
Realistic design with real size dimensions
Backlighted text in the display area for ADF/ANT selections
Direct daisy-chain connection to MCP737 through single 5 pole cable (provided)
Easy jumper selection to set ADF1 or ADF2 functionality
5 pole connection cable ( 70 cm - provided )
The module is supplied with aluminium fasteners, screws and nuts (optional 1/4 turn original fastners)
Compatible with Flight Simulator X, Flight Simulator Steam Edition, Prepar 3D ( all releases ), Project Magenta, PROSIM737, SimAvionics, PMDG737NGX, iFly737, LVLD767, xPlane.
ADF737 is an expansion module and requires MCP737EL or MCP737PRO/PRO2 to operate.
Full scale replica of Boeing 737 transponder radio
Warm white backlight, yellow digit and double dual concentric encoder
Realistic design with real size dimensions
Backlighted text in the display area for ATC 1/2 selections
Direct daisy-chain connection to MCP737 through single 5 pole cable (lenght 70 cm - provided)
5 pole connection cable ( 70 cm - provided )
The module is supplied with aluminium fasteners, screws and nuts (optional 1/4 turn original fastners)
Compatible with Flight Simulator X, Flight Simulator Steam Edition, Prepar 3D ( all releases ), Project Magenta, PROSIM737, SimAvionics, PMDG737NGX, iFly737, LVLD767, xPlane.
ATC737 is an expansion module and requires MCP737EL or MCP737PRO/PRO2 to operate.
Frequency, STBY and IDENT functions compatible with IVAO.
Full scale replica of Boeing 737 Trim panel
Warm white backlight
Backlighted Rudder knob
LCD graphical display
Direct plug CPflight daisy chain (CPflight MCP required )
5 pole connection cable (70 cm - provided )
The module is supplied with aluminium fasteners, screws and nuts (optional 1/4 turn original fastners)
Compatible with Flight Simulator X, Flight Simulator Steam Edition, Prepar 3D ( V1, V2 and V3), Project Magenta, PROSIM737, SimAvionics, PMDG737NGX, iFly737, LVLD767, xPlane.
TRIM737 is an expansion modules and requires MCP737EL or MCP737PRO/PRO2 to operate.
Full scale replica of Boeing 737 Fire panel
Warm white backlight
Handles with lift-UP/LEFT/RIGHT positions and "Hard Click" feeling
Locking mechanism with automatic unlock and manual override pushbuttons
All switches and pushbuttons are operating
All annunciators are operating
Direct plug CPflight daisy chain (CPflight MCP required)
The module is supplied with aluminium fasteners, screws and nuts (optional 1/4 original turn fastners)
Compatible with Flight Simulator X, Flight Simulator Steam Edition, Prepar 3D ( V1, V2, V3, V4 and V5), Project Magenta, PROSIM737, PMDG737NGX, iFly737. Please check our section "Technical and documents".
FIRE737 is an expansion module and requires MCP737EL or MCP737PRO/PRO2/PRO3/NG-MAX to operate.
Full scale replica Boeing 737 of CP & FO Audio Selector panel
Warm white backlight
High quality backlighted pushbuttons and MIC selectors
The module is supplied with aluminium fasteners, screws and nuts (optional ¼ turn fastners)
10 bit resolution for volume regulation on each channel
14 potentiometers with latching push functions and illuminated knob
1 high quality locking lever, 1 R/T- I/C 3 position momentary switch, 1 ALT/NORM 2 position switch, 1 VBR 3 position rotary selector.
Direct daisy-chain connection to MCP737 through single 5 pole cable (70 cm provided).
Full scale replica Boeing 737 CARGO panel
Warm white backlight
Directly plug CPflight daisy chain (CPflight MCP required)
5 pole connection cable (70 cm-provided)
The module is supplied with aluminium fasteners, screws and nuts. (optional 1/4 turn original fastners)
Compatible with Flight Simulator X, Flight Simulator Steam Edition, Prepar 3D ( V1, V2 and V3), Project Magenta, PROSIM737, PMDG737NGX, iFly737.
Full scale replica Boeing 737 WXR panel
Warm white backlight
Direct plug CPflight daisy chain (CPflight MCP required)
5 pole connection cable (70 cm-provided)
The module is supplied with aluminium fasteners, screws and nuts ( (optional 1/4 turn original fastners)
Compatible with Flight Simulator X, Flight Simulator Steam Edition, Prepar 3D ( V1, V2,V3,V4 and V5) if used with Project Magenta, PROSIM737 V3 or PMDG737NGX or NGXu.
11 not latching pushbutton
2 lacthing pushbutton
2 knobs with dual shaft potentiometer to regulate left and right side
Full replica of brightness regulation module
6vdc 2 A power supply adapter
3,5 lenght mt 5 pole cable (dedicated)
High realism panel with warm white backlight
1 Knob for the pedestal backlight brightness regulation
1 Knob for the eventual FLOOD (on the dedicated terminal block).
2 sockets to connect SELCAL/CABDOOR737
1 DIN 5 pole socket for the connection to the CPflight MCP737
3 DIN 5 pole socket to connect all the other pedestal panels
Supplied with aluminium fasteners, screws and nuts (optional 1/4 turn original fastners and backlighted knob)
100% scaled
Backlighted knobs
Works with all CPflight MCP versions.
CABDOOR737 reproduces the analogous module present on the 737NG pedestal.
2 positions stab trim switch with guard
High realism panel with warm white backlight
Contact input for "CABIN DOOR" status
2 annunciators, "LOCK FAIL"- "AUTO UNLOCK"
1 three positions commutator, "UNLOCKED"- "AUTO"- "DENY"
1 flat cable (integrated) used to connect to the BRT737NG panel.
Supplied with aluminium fasteners, screws and nuts (optional 1/4 turn original fastners)
100% scaled
Works with all CPflight MCP versions.
The SELCAL737 reproduces the analogous panel present on the 737NG pedestal.
5 warning pushbuttons: VHF1, VHF2, VHF3, HF1 and HF2
5 warm white annunciators
Supplied with aluminium fasteners, screws and nuts (optional 1/4 turn fastners)
1 flat cable (integrated) to connect SELCAL panel to the BRT737NG.
SIDE board with CP and FO Warnings and SIXPACK.
Plug & play module that allows to connect the glareshield warnings.
Flat cables to connect the warnings are provided.
Compatible with Flight Simulator X, Flight Simulator Steam Edition, Prepar 3D ( V1, V2 and V3), Project Magenta, PROSIM737, SimAvionics, PMDG737NGX, iFly737, LVLD767, XP11 ( only ZIBO737 ).
SIDE737 is an expansion module and requires MCP737EL or MCP737PRO/PRO2 to operate.
SIXPACK recall annunciator for CP side (Common Anode) - NOT SUITABLE for MIP737SE connection.
SIXPACK recall annunciator for FO side (Common Anode). NOT suitable for MIP737SE.
SIXPACK recall annunciator for CP side (Common Cathode) - SUITABLE for MIP737SE connection
SIXPACK recall annunciator for FO side (Common cathode)
Full aluminium anosided sixpack recall annunciator with 1 mt cable provided to your MIP737SE or interface board. COMPATIBLE WITH MIP737SE.
